Stainless Steel Filter Element
304 oil filter cartridge
SUS 304 mesh filter
Customized oil filter
5 micron SUS 304 mesh filter
Stainless Steel Filter Element
304 oil filter cartridge
SUS 304 mesh filter
Customized oil filter
5 micron SUS 304 mesh filter

5micron stainless steel 304 filter

Share:
Product Description
The stainless steel filter element uses a stainless steel woven mesh as the main filter medium, the sealing surfaces of the filter element are joined by argon arc welding. The filter layer adopts a multi-fold process to form a complete filter element without leakage or media falling off.
Technical Parameters
1. It has good resistance to high temperature and pressure and chemical corrosion resistance.
2. It has excellent air permeability, large dirt holding capacity, high strength, good sealing, long life, and can be cleaned and used repeatedly.
3. Working temperature: -60-500℃.
4. The pressure difference that the filter element bears: 2MPa.


Name 5micron Stainless steeel mesh filter
Size 350x650mm (Customized)
End cover SS304
Frame  SS304 punching plate
Inner filter layer 304 stainless steel mesh 5μm


Advantages
01
Good filtration performance, 2-200um filter particle size can play a uniform surface filtration performance.
02
Good corrosion resistance, heat resistance, pressure resistance and wear resistance;
03
Filter hole uniform, accurate filtration accuracy;
04
Filter is suitable for all kinds of hydraulic environment;Can be used after cleaning, no replacement.



Production process
Check manufacturing drawing---Prepare raw material --- Pleated wave ---Opposite joint---Assembly---Inspection---Test --Packing---Transport and shipping
