Pleated Filter

Pleated Filter

Pleated Filter

Pleated Filter

Pleated Filter

Pleated Filter

Pleated Filter

Pleated Filter

pp folding water filter

Filter material:

PP, PES, PTFE, nylon, etc;

Filtration accuracy:

0.1um, 0.22um, 0.45um, 1um, 3um, 5um, 10um, 20um, 30um, 50um;

Filter element length:

5”, 10”, 20”, 30”, 40”

Share:

Product Description

Technical Parameters

Application field

Product Description

Microporous folding filter adopts polypropylene fiber membrane (PP), nylon film (NL), polysulfone (PS),polytetrafluoroethylene (PTEF) ,polyvinylidene fluoride (PVDF), and non-woven (screen) support layers folded, the filter shell,central core and end caps using hot melt welding technology processing molding,without any glue, no leakage,no secondary pollution. Through the micron screen filtering of the membrane surface to achieve a certain role in particle filtration.

Technical Parameters

* Filter material: PP, PES, PTFE, nylon, etc;
* Filtration accuracy: 0.1um, 0.22um, 0.45um, 1um, 3um, 5um, 10um, 20um, 30um, 50um;
* Filter element length: 5”, 10”, 20”, 30”, 40”
* Filter element outer diameter: 69mm
* Inner diameter of filter element: 29mm 　　
* PH value: 1-13
* Main connection methods: flat, bayonet, socket, 222, 226, 215
* Maximum working temperature: 0.1MPa (≤80℃)
* Maximum working pressure: 0.3MPa at 50℃
* Maximum back pressure difference: 0.2MPa at 25℃
* Maximum disinfection temperature: 120℃

Advantages

01

Excellent chemical compatibility,suitable for filtering strong acid,alkali and organic solvents

02

Deep folding filtration,large membrane filtration area

03

Low pressure differ,large pollution capacity, long service life

04

Gradual pore size changes provide ultra-high capacity

Show Details

Application field

Pharmaceutical industry

pre-filtration of various liquid medicines

Food and beverage industry

filtration of alcohol, mineral water and drinking water

Petroleum industry

oilfield water injection filtration

Electronics industry

high-purity water pre-filtration

Chemical industry

filtration of various organic solvents, acids and lyes, pure water filtration of various cosmetic solutions

Inquiry

We have rich experience and capacity to deal with big order and projects.
